Oil pan gasket bbc
I am reinstalling my timing cover and oil pan. I am using a 1 piece pan gasket. Do I still need to install the lower gasket for the timing cover?
-
04-10-2010 #2
Registered User
- Join Date
- Apr 2005
- Location
- Bonney Lake, WA
- Posts
- 135
any one?
Im just sitting here waiting because im not sure what to do. Any help would be appreciated.
04-10-2010 #3
Registered User
- Join Date
- Jan 2002
- Location
- Crockett, Texas
- Posts
- 568
No, the one-piece pan gasket has it's own "nipples" that go through the timing cover.
Not the best pic but you can see a little.
Don 67 Camaro RS/SS Texas
04-10-2010 #4
Registered User
- Join Date
- Jan 2006
- Location
- Murphy, TX
- Posts
- 82
I did a Fel-Pro one piece gasket on a BBC about 2 weeks ago and had a leak around the first two bolts going in to the timing cover. It was leaking even before running the engine. I pulled the pan off and put silicon seal around all four corners. It sealed up and no leaks after 5 pulls on an engine dyno. My advice is to silicon all four corners of your pan.
04-10-2010 #5
Registered User
- Join Date
- Apr 2005
- Location
- Bonney Lake, WA
- Posts
- 135
Thanks
Guys. Thanks for the info. I see the nipples, I get it now. I will silicone the corners. I would not have, so thanks for that tip.
Jay.
