Thread: Fat lip?
-
03-09-2006 #1
-Moderator-
- Join Date
- Jul 2005
- Location
- Mountain View, CA
- Posts
- 9,583
Fat lip?
Anyone have a photographic example of the same wheel in fat and non-fat lip design?
I don't quite get what the difference is.
True T.
Whats new with Project 1/2-Trak?
Follow my wisecracks on Sports, Food, Politics and other BS on Twitter.
My blog
When they kick out your front door, How you gonna come?
With your hands on your head, Or on the trigger of your gun?
-
03-09-2006 #2
Registered User
- Join Date
- Sep 2005
- Posts
- 15
Vintec with classic hoop:
Vintec with soft lip:
Notice the difference? There are no "steps" between the outer edge of the hoop and the face of the wheel.DENIAL 2001 Sierra RCSB, 11.578 @ 118.98
LS1/80-E, TR224, Yank TT3200, NX MAF kit, Cal Tracs, 4.11's/Eaton, M&H DR's
03-09-2006 #3
Registered User
- Join Date
- Aug 2004
- Location
- Lees Summit, Missouri
- Posts
- 843
One has the tradiyional "stepped" lip, the fat lip is smooyh to the edge of the wheel.
Later - Craig
[email protected]
'70 Chevelle (in storage now, probably will never be back on its wheels again!)
03-09-2006 #4
Registered User
- Join Date
- Nov 2004
- Location
- NW Arkansas
- Posts
- 1,742
the tire has to go on from the back on a soft/fat lip style
KENNY DAVIS HOTRODS
03-09-2006 #5
Registered User
- Join Date
- Jan 2005
- Location
- Hayesville,NC
- Posts
- 297
Fat lip gives a 17" wheel the look of 18" so you can run a little more sidewall and still have a big wheel look.I think they look great!!!!!
03-09-2006 #6
Pro-Touring Veteran
- Join Date
- Jun 2002
- Location
- Long Island, NY
- Posts
- 11,320
Side View (excuse the rusty rotor):
03-09-2006 #7
Registered User
- Join Date
- Aug 2004
- Posts
- 341
Originally Posted by 1981silverz28
They also cut down on clearance for break caliper clearance.Stuart Seitz
03-15-2006 #8
Registered User
- Join Date
- Feb 2006
- Location
- Huntington Beach, Ca
- Posts
- 10
if that you mean by 0.20"@max back space. Other wise The Fat-Lip outer has a larger ID @ min back space than a traditional lip. Originally Posted by JoeleanLS1
03-15-2006 #9
Registered User
- Join Date
- Oct 2003
- Location
- Arvada, Co
- Posts
- 2,119
Uh no. It has a larger ID on the outboard side of the rim, but it still has the hump. It was just moved more towards the center of the rim. Hence the less brake caliper clearance. Ask Larry about that. Originally Posted by JasonSS
Brian
I have an unlimited budget. That bad part is I have already used it up.
03-16-2006 #10
Registered User
- Join Date
- Mar 2006
- Location
- Lafayette
- Posts
- 296
Here are the wheels im running on my pro-touring themed 98 Sonoma. They are 17x8/10's with 4.5 backspacing. The where made by Intro and sold by CoysWheel.com out of Utah. Originally Posted by Damn True
Scott
Built LTX, TKO600, 12Bolt
03-16-2006 #11
Registered User
- Join Date
- Aug 2004
- Location
- Red Deer, Alberta, Canada
- Posts
- 1,364
This is the best I could find...
Fat Lip
Normal Lip
-MattMatt
72 Chevelle 370ci, 76mm single turbo, TKX, Speedtech Track Time, Millerbuilt Strange full floater 9", Brembo brakes, BC Forged 18x11s with 315s square
Instagram: Cst_koon
03-16-2006 #12
Registered User
- Join Date
- Apr 2002
- Location
- North Central Texas
- Posts
- 720
I love the Fat/Soft lip design, but it does have a draw back. I found this out after I received my BOYD "FURY" wheels (17x8 up front). If you are running C5 rotors (13") and Z06 calipers you will have to grind some of the height off of the fins on the caliper. They drag just ever so slightly. There is a step on the inside of my wheels that the caliper interferes with. I did notice in the pics above in the earlier post that those wheels have the same inner lip that I am refering to. I don't know if ever Fat/Soft lip wheel has this issue or not but mine did. It wasn't a big deal to fix it was just unexpected.
